Z-400.2 SP

Ask question about this product

Price : 78000.- บาท


Product Description

The Z-SP Series. Super Power Amplifiers.


In 2011 Zapco produced the new Z-Series Competition amps, and the response was incredible. Testers thought it was our best work ever and the new amps were snapped up by sound-off competitors around the country. With the new Z-Series SP, there are now four Zapco Competition series products based on the same amplifier. The Z-AP, the Z-SP, the Z-II, and the ZX amplifiers. The specifications of the Competition series amps don’t change but each is tweaked to a specific purpose.

A purpose-built competition series amplifier is the Z-SP amplifier, as in Super Power or Street Power. This series comes from the need to outfit cars that compete in the new category called “Street Challenge” in some competitions it’s called “Street Demo”.
What is “Street Power”? Literally, amplifier power for the Street; an amplifier that will be used on the street, in the open spaces, with the door open, and cranked up for all to hear.
If you want competition level sound quality and want to blow the doors off at the same time, these are your amplifiers.


If you want competition level sound quality and want to blow the doors off at the same time, these are your amplifiers


About Z-Series SP amplifiers


This series comes from the need to outfit cars that compete in the new category called "Street Challange" or "Street Demo". This is harder on the components and creates more heat than audiophile listening because they will be played full power, full time.
They need to produce the highest volume (Sound Pressure) possible while still maintaining clear sound. Not like audiophile listening so much as like a dance hall or rock concert.

The Z-Series SP amps were a chance to make a completely new project. To reach our goals we first developed a new forced air cooling system in a chassis with internal heat sink fins and fans to blow the heat off the chassis. Fans blow on to the fins to move air down the chassis, and the side vents down the side create turbulence that sends hot air out and cold air in along the whole length of the amp. This got us half way there. Then we found a new space-age material, to insulate the output transistors, that can pull heat off devices much faster than the standard insulators. So now we could transfer the heat from the devices to the chassis faster then pull the heat off the chassis faster.
The result: We now had an amplifier that you can crank up to full volume and play that way all day long. And, with a few upgrades in circuitry that we made, you also get: High Pass, Low Pass, and Band Pass crossovers, x10 Range Switch for accurate crossover frequency selection, Variable Sub Sonic filter using the band pass, Variable Bass Boost, Variable Gain, Auxiliary RCA Output, Available Dash Remote.
In most amplifiers all these preamp controls give you more versatility but they also rob you of signal quality. But in the Zapco Z-Series SP amps, even with crossovers and bass boost you get over 103dB signal to noise ratio, less than 0.1% THD, and greater than 60dB channel separation. And the SP amps get a 10% power gain from increased thermal efficiency that reduces the "de-rating" of the output devices.
A quick rundown of the SP amp's unique features:

• Cooling fans with thermal speed control
• Insulator with 70% less thermal resistance of MICA for faster heat transfer
• Proprietary RCA connectors with extra heavy plating soldered directly on the PCB
(Zapco design) with 6 ground lugs on each, for an absolutely secure mount
• Balanced and differential inputs with one tenth the normal resistance
• New Op-amp with lower noise than even the current LX amps
• Bass Boost that is out of the circuit when set to 0
• Capacitors with lower internal resistance and lower inductance (only just now appearing in the LX amps)
• Fine adjustment for bias in each channel
• A custom plaque with model and serial number lets them know this amp is special


We sincerely hope you enjoy your new Z-Series SP amplifier as much as we
enjoyed the time we spent developing it.





  • 2-Channel Street Power competition amplifier

  • Wide range dual crossovers allowing band-pass filtering

  • Variable bass boost

  • Variable subsonic filter

  • Ducted Air fan cooling system

  • Space-age technology for cooler output devices

  • Proprietary gold panel mount RCA Connectors

  • Dash mount remote gain control available

  • Power @ 4Ω: 2 x 440 watts

  • Power @ 2Ω: 2 x 700 watts

  • Power @ 4Ω Bridged: 1 x 1400 watts

  • THD @ Rated Power  < 0.05%

  • Signal to Noise Ratio > 104dB

  • Channel separation > 60dB

  • Frequency Response 10Hz to 30,000Hz ±1dB

  • Input Sensitivity .25v to 8v

  • Dimensions in mm: 241(W) x 62(H) x 482(L) Overall: 241(W) x 62(H) x 514(L)
