Parameters

Dimensions

54 x 135 x 308 mm

Weight

2.4 Kg

Supply voltage

12 v

External fuse

60 A

Internal fuse

No

Built-in cooling fan

Yes

Maximum current

64 (35) A

Standby Current Consumption

0.7 (0.35) A

Bass EQ @ 60 Hz

Yes

High pass filter

(on / off) 50-500 Hz

Low pass filter

(on / off) 50-500 Hz

High level entrance

Yes

Input sensitivity

1-4 V

Input impedance, high level

45 ohm

Input impedance, low

5000 ohm

Operating frequency range

10-60000 Hz

Attenuation coefficient

> 300

Signal to noise ratio, weighted average

110 dB

Bridge power

2 channels of 290 W each

Power at 2 Ohm (RMS)

4 channels of 150watts

Power at 4 Ohm (RMS)

4 channels of 85 W each

Amplifier class

A / B

Number of channels

4
