Product Description
The P-1 Monaural Power Amplifier is our next-generation flagship model featuring MAGNEOLA magnesium alloy specially designed for use in audio equipment, low heat generation and low power consumption technology, stylish design without heat dissipation fins, ultra light weight at only 645g and with a rated output of 100W. Sound quality is the top priority of the discrete structure of the circuit which follows the principles of our Air Circuit concept, with the latest generation BSZ1 acoustic operational amplifier developed in conjunction with New Japan Radio Co., Ltd., and the new MUSES7001 large capacity SiC (silicon carbide) diode used in both the positive and negative power supply units, a driver stage dedicated power supply unit which separates the power supply to each stage from driver to final output, and newly designed printed circuit boards of a uniform 70μm thickness, delivering overwhelming musical expressiveness and drive power with outstanding S/N ratio.
100W Monaural Power Amplifier
P-1
Power Source | 14.4V DC (11.0 – 15.0V allowable) |
---|---|
Continuous Power Output | 100W x 1ch (14.4V : 4Ω : 20 – 20kHz : 0.03%THD) |
Frequency Response | 10 – 40,000Hz (-1dB) |
Signal to Noise Ratio | 99dB |
Load Impedance | 4Ω |
Damping Factor | 450 (4Ω:100Hz) |
Input Level | 0.2 – 6.0V |
Fuse | 10A x 1 |
Size | W251 x D80 x H43 mm |
Weight | 645g |
